The V10 is the same bike ridden by the Syndicate to World Cup victories. Fully refined, not redefined, the new V10 is for riders looking to just imitate their heroes on Sunday afternoon or find the best lines in the bike park. The kind of rider who knows there’s no replacement for a proper downhill bike. Lap after lap, day after day nothing stands up to the abuse or gives the thrills a downhill bike can. Nothing.

Specs

Please note: We make every effort to ensure the accuracy of spec information, but they are subject to change.

Frame & Suspension

Material: Carbon CC
Shock: Fox DHX2 Factory Coil

Specs

Headset: IS41 upper / IS41 lower (Reach Adjust)
Seat Post Diameter: 31.6mm
Seat Clamp Diameter: 36.4mm
Bottom Bracket Shell: 83mm Threaded
Max Tire Clearance: 2.5"
Max Chainring Size: 36t
Shock Length: 250mm
Shock Stroke: 75mm
Shock Bushing Size (Front): 30x8
Shock Bushing Size (Rear): 30x8

Geometry

Shock Position: Low

All units are in millimeters or degrees.

	S	M	L	XL
A. Reach (Long/Mid/Short)	409-417-425	444-452-460	464-472-480	489-497-505
B. Stack	626	635	639	644
Head tube angle	62.7	62.7	62.7	62.7
K. Head Tube Length	100	110	115	120
G. Rear Center (Long/Mid/Short)	440-445-452	446-451-456	451-456-461	456-461-466
F. Front Center	785	825	847	874
H. BB Height	351	351	351	351
Bb drop front	21	21	21	21
Bb drop rear	3	3	3	21
E. Wheelbase	1231	1276	1303	1335
L. Seat Tube Length	435	445	455	465
D. Seat Tube Angle	77.6	77.1	77	76.7
J. Standover Height	724	726	726	726
