2027 BMC Teammachine SLR Three
The Teammachine SLR THREE shares the same Advanced Carbon frame that defines the SLR platform, delivering a road bike built to defy gravity with efficiency, stability, and precision, in a package that’s more accessible. Refined over more than a decade, this iteration continues to raise the standard for stiffness-to-weight performance, making for ultra-efficient power transfer on the climbs and responsive handling on the way back down. As the introduction to our flagship climbing bike range, it also carries the full suite of BMC design intelligence: TCC Race compliance construction, our signature D-shape carbon seatpost, ensuring comfort doesn’t come at the cost of control. The ride stays composed when surfaces deteriorate and direct when precision matters most. Equipped with Shimano 105 groupset and finished with our RSM01 stem, alloy bars, and dependable PRD23 wheels, the Teammachine SLR THREE keeps your focus on the road ahead and the climb you’re already committed to.
Specs
Frameset
Frame:
Teammachine SLR Gen 5 | Advanced Carbon with Aerocore Design | ICS Technology Stealth Cable Routing | Full Mount - UDH | TCC Race compliance level | Flat Mount Disc | 12 x 142mm Thru-Axle | Optimized for Aerocore Bottle Cages
Fork:
Teammachine SLR Gen 5 | Advanced Carbon | ICS Technology Stealth Cable Routing | TCC Race Compliance Level | Stealth Dropout Design | Flat Mount Disc | 12 x 100mm Thru-Axle | 48mm offset Size 47-51 | 43mm offset Size 54-61
Cockpit
Stem:
BMC RSM 01 | Integrated Cockpit System Technology
Handlebar:
BMC HB D4 03, 0, 6 | Alloy 6061 | Race Geometry | 135mm drop, 70mm reach, 6° flare
Grips:
BMC Tacky 3mm
Seat
Seatpost:
Teammachine SLR 01 Gen 5 | Advanced Carbon Aero Shaped Seatpost | 0mm Offset Size 47-51 and 10mm Offset Size 54-61
Saddle:
Selle Italia Model X Greentech | FeC Alloy Rail | 145mm
Drivetrain
Crankset:
SHIMANO 105 (FC-R7100)
Chainrings:
52-36T
Cassette:
SHIMANO (CS-HG710)
Cassette Size:
11-36T
Chain:
SHIMANO CN-M6100
Front Derailleur:
SHIMANO 105 (FD-R7100)
Rear Derailleur:
SHIMANO 105 (RD-R7100)
Shifters:
SHIMANO 105 (ST-R7120)
Gears:
2 x 12
Bottom Bracket:
SHIMANO Press-Fit Bottom Bracket (BB-RS500-PB)
Brakes
Brake Levers / Calipers:
SHIMANO 105 (BR-R7170)
Rotors:
SHIMANO SM-RT54 | Centerlock
Rotor Size (F/R):
160 / 160mm
Wheels
Rims:
PRD23 | 23mm
Hubs (F/R):
SHIMANO HB-TC500-12 & FH-TC500-HL | Center Lock| 28H
Tires:
Contiental Grand Prix | Tube type | 28mm
Tubeless Information:
Non-Tubeless Rims | Tubeless Clincher Tire
Additional Information
Tire Clearance:
32mm measured tire
Weight without Pedals:
8.7kg | Size 54 as pictured with all accessories
ASTM Classification:
Level 1
System Weight Limit:
110kg
General Product Safety Regulation (GPSR):
Safety Instructions GPSR (EU)
Responsible person according to GPSR (EU)
Color Reference
Color Code:
wht blk blk
Marketing Color:
Cool White
Paint Direction:
Cromax Z6007
HEX Display:
#dae7f2
LAB Color Scan:
92.00, -3.00, -7.00
Geometry
| Size | 47 | 51 | 54 | 56 | 58 | 61 |
|---|---|---|---|---|---|---|
| Rider Height | <166 | 166-174 | 172-180 | 178-186 | 184-192 | >190 |
| Reach | 367 | 377 | 386 | 392 | 401 | 409 |
| Stack | 506 | 530 | 550 | 565 | 584 | 608 |
| Bar Drop | 125 | 125 | 125 | 125 | 125 | 125 |
| Bar Reach | 80 | 80 | 80 | 80 | 80 | 80 |
| Bar Width | 390/414 | 390/414 | 390/414 | 410/434 | 410/434 | 410/434 |
| BB Drop | 69 | 69 | 69 | 69 | 69 | 69 |
| Crank Length | 165 | 170 | 170 | 170 | 172.5 | 172.5 |
| Fork Length | 369 | 369 | 369 | 369 | 369 | 369 |
| Fork Rake | 48 | 48 | 43 | 43 | 43 | 43 |
| Front Center | 568 | 586 | 589 | 599 | 614 | 630 |
| Head Tube | 108 | 133 | 149 | 165 | 184 | 211 |
| Head Tube Angle | 71.5° | 71.5° | 72.3° | 72.3° | 72.3° | 72.3° |
| Rear Center | 410 | 410 | 410 | 410 | 410 | 410 |
| Seat Angle | 74° | 74° | 73.5° | 73.5° | 73° | 73° |
| Seat Tube | 422 | 464 | 491 | 509 | 530 | 555 |
| Seatpost Length | 335 | 335 | 385 | 385 | 405 | 405 |
| Seatpost Offset | 0 | 0 | 10 | 10 | 10 | 10 |
| Standover Height | 717 | 752 | 779 | 797 | 817 | 843 |
| Stem Angle | -8° | -8° | -8° | -8° | -8° | -8° |
| Stem Length | 70 | 90 | 90 | 100 | 110 | 110 |
| Top Tube | 515 | 532 | 552 | 562 | 582 | 598 |
| Trail | 63 | 63 | 63 | 63 | 63 | 63 |
| Wheelbase | 968 | 986 | 989 | 1000 | 1015 | 1030 |
