The Norco Fluid FS A3 is built to tackle whatever trail leads to becoming the rider you want to be. Named Pinkbike’s Value Bike of the Year, Vital MTB’s Bike of the Year, and most recently, Bicycling Magazine’s Best Value Trail Bike.

Get everything out of the trail that you put into it.

The Fluid FS A3's 130mm travel is precision engineered, pairing custom tuned suspension components with 140mm fork travel and boutique level fit & finish for maximum Trail performance & potential.



Specs

Frameset
• Frame: 6061 Alloy, 130mm Travel, UDH, Hangerless Interface Compatible, Ride Aligned™
• Fork: RockShox Recon RL, 140mm, 29"
• Rear Shock: X-Fusion 02 Pro R AV, 130mm

Drivetrain
• Rear Shifter: Shimano CUES 10 SL-U6000 Rapidfire Plus
• Rear Derailleur: Shimano CUES RD-U6020, 10-Speed
• Crankset: FSA Comet 1X DM, 30T
• Bottom Bracket: FSA MegaExo
• Cassette: Shimano CUES LG-400, 10-Speed, 11–48T
• Chain: Shimano LG-500

Brakes
• Front Brake: Tektro HD-M535, 4-Piston, 180mm
• Front Brake Rotor: Tektro TR180-22, 180mm
• Rear Brake: Tektro HD-M535, 4-Piston, 180mm
• Rear Brake Rotor: Tektro TR180-22, 180mm
• Brake Levers: Tektro HD-M535

Components
• Handlebar: Norco 6061 DB Alloy, 800mm, 25mm Rise
• Stem: Norco 6061 Alloy, 40mm Length, 35mm Clamp
• Seatpost: TranzX YSI34, 34.9mm
• Headset: Zero Stack Sealed Cartridge Bearings, Tapered
• Headset Spacer: 1 x 10mm
• Saddle: Norco Trail Saddle
• Grips: Propalm Pro Grips
• Pedals: VP Nylon Flat Pedals
• Seatpost Clamp: Norco Alloy Nutted Clamp

Wheels
• Front Hub: Formula DC-511, 110x15, 32H
• Rear Hub: Formula DC-3248, 148x12, 32H
• Rims: WTB ST 29", 32H
• Front Tire: Continental Kryptotal Trail, 29" x 2.4"
• Rear Tire: Continental Xynotal Trail, 29" x 2.4"
• Front Hub Skewer: SR Suntour TA
• Rear Hub Skewer: 148mm x 12mm TA
• Spokes/Nipples: Stainless Steel, 14g, Black

Geometry

		S	M	L	XL	XXL
	Wheel Size	29"	29"	29"	29"	29"
	Travel (mm front/mm rear)	140/130
	Reach	420	450	480	510	540
	Stack	617	626	635	644	653
HTA	Head Tube Angle	65
OS	Fork Offset	44
ST	Seat Tube Length	360	390	410	460	510
STA	Effective Seat Tube Angle	76	76.3	76.7	77	77.3
RC	Rear Centre Length	425	430	435	440	445
BB	Bottom Bracket Drop	30
BBH	Bottom Bracket Height	348
HTT	Horizontal Top Tube	574	602	630	659	687
WB	Wheelbase	1166	1205	1245	1284	1323
SOH	Standover	678	690	699	736	767
HT	Head Tube Length	110	120	130	140	150
	Trail	128
	Recommended Seatpost Drop	150	170	200
	Maximum Post Insertion	250	270	300
	Stem Length	40
	Crank Length	175
	Tire Size	2.4" – 2.6"
	Water Bottle Compatible	1 x 750 mL				1 x 750 mL and 1 x 620 mL
