The Scene VLT is a 2x award winning, ultra-versatile, relaxed electric hybrid that gets around easily. With a flat bar and comfortable upright riding position, the Scene VLT replaces the need for a car in the city. With the Shimano STEPS motor, and 504Wh battery, the Scene VLT makes even the hilliest rides no sweat at all.

Rides like a pedal bike, but with all the power!

The nearly silent yet powerful Shimano STEPS drive system is integrated into the Scene VLT’s beautiful aluminum frame with a lower center of gravity for stress-free mounts and dismounts, and easy maneuverability.

Details

• Winner, ProtégezVous Magazine Consumer's choice award.
• Sleek, custom formed aluminum step-thru frame.
• Streamlined cockpit with compact display, dropper post, gear shifter, and integrated lighting.
• Automatic dropper post for instant, easy saddle adjustment.
• High volume tires and hydraulic brakes for ultimate stopping control.
• Rides like a pedal Scene, but faster!
• No Other Way Limited Lifetime Warranty.

Specifications

Frameset

• Frame: Double Butted Alloy E-Bike Frame, Internal Cable Routing

• Fork: Aluminum Thru-Axle, with Light Mount

Drivetrain

• Rear Shifter: Shimano Alivio SL-M3100

• Rear Derailleur: Shimano Alivio RD-M3100

• Crankset: Shimano 38T, 165mm

• Cassette: Shimano CS-HG200-9, 11-36T, 9-speed

• Chain: KMC e-9 Sport

Brakes

• Front Brake: Tektro HD-M285, Hydraulic Disc, E-Rated, Resin Pads

• Front Brake Rotor: 160mm, 6-bolt

• Rear Brake: Tektro HD-M285, Hydraulic Disc, E-Rated, Resin Pads

• Rear Brake Rotor: 160mm, 6-bolt

• Brake Levers: Tektro HD-M285

Components

• Handlebar: Scene Custom High Rise City Bar

• Stem: Alloy, 17° Rise

• Seatpost: Adjustable TransX Dropper, 31.6mm

• Headset: Zero Stack

• Headset Spacers: 2 x 10mm, 1 x 5mm

• Saddle: Scene Comfort Saddle with Elastomer Suspension

• Grips: Dual Density Ergonomic Grip with Single Lock

• Pedals: City Pedals with Traction Inlay

• Seatpost Clamp: Alloy Quick Release

Wheels

• Front Hub: Sealed Bearing, 15x100mm, 6-bolt

• Rear Hub: Sealed Bearing, 12x142mm, HG, 6-bolt

• Rims: Alloy DW Disc, 27.5"

• Front Tire: Kenda Kwick Seven5, 27.5" x 2.2", 30 TPI

• Rear Tire: Kenda Kwick Seven5, 27.5" x 2.2", 30 TPI

• Front Hub Skewer: Tooled Thru-Axle

• Rear Hub Skewer: Tooled Thru-Axle

• Spokes/Nipples: Stainless Black

• Valves: Standard

• Tubes: 27.5 x 2.1–2.35

• Rim Tape: Nylon + PVC Rim Tape

Electric Components

• Motor: Shimano EP6, 85Nm

• Battery: Shimano BT-EN605, 504Wh

• Display: Shimano SC-EN500 with Integrated Switch

Geometry

		L	M	S
	Wheel Size	27.5"	27.5"	27.5"
	Reach	375	365	355
	Stack	649	621	593
HTA	Head Tube Angle	68
OS	Fork Offset	50
ST	Seat Tube Length	475	450	425
STA	Effective Seat Tube Angle	68
RC	Rear Centre Length	470
BB	Bottom Bracket Drop	67
BBH	Bottom Bracket Height	285
HTT	Horizontal Top Tube	637	616	595
WB	Wheelbase	1129	1108	1087
SOH	Standover	415
HT	Head Tube Length	230	200	170
	Trail	88
	Recommended Seatpost Drop	120		100
	Maximum Post Insertion	300	250
	Stem Length	70
	Crank Length	170
	Tire Size	2.0" – 2.35"
	Water Bottle Compatible	1 x 750 mL
