The Storm features a progressive off-road design and features that’ll help you discover your favourite way to ride.

The Storm opens up the world of off-road adventure.

It’s built for off-road adventure, but the lightweight aluminum Storm is more than happy to lead a double life on city streets and park paths.

Details

• Progressive design for nimble, confident trail performance.
• The perfect amount of suspension for comfort and control on the trail.
• Mechanical systems protected from the elements.
• Stop on a dime.
• Size-specific wheels optimize the ride.
• Versatile frame features to take you anywhere.
• No Other Way Limited Lifetime Warranty.

Specs

Frameset

• Frame: Aluminum | TIG Welding | Tapered Head Tube | 10x135mm QR

• Fork: Suntour XCT-30 DS Coil | 100mm Travel | 46mm Offset | 9x100mm QR

Drivetrain

• Rear Shifter: Shimano Altus SL-M315 | 8-Speed

• Rear Derailleur: Shimano Essa RD-U2000 | 8-Speed | Shadow Design

• Crankset: Prowheel Alloy | 30T

  • 170mm (S–M) | 175mm (L–XXL)

• Bottom Bracket: Cartridge | ST 73mm | 113mm Axle Length

• Cassette: Shimano CS-HG400-8 | 11–45T | 8-Speed

• Chain: KMC Z8

Brakes

• Front Brake: C-Star BX-351 | Mechanical Disc

• Rear Brake: C-Star BX-351 | Mechanical Disc

• Front Rotor: C-Star | 160mm | 6-Bolt

• Rear Rotor: C-Star | 160mm | 6-Bolt

• Brake Levers: C-Star VL-801D | Mechanical Disc

Components

• Handlebar: 6062 Alloy DB 6.1 | 760mm Width | 30mm Rise

• Stem: Alloy | 45mm Length | 31.8mm Clamp

• Seatpost: Alloy | 31.6mm Diameter | 300mm Length

• Headset: Zero Stack | 1-1/8" Steer

  • ZS44/28.6 (Top) | ZS44/30 (Bottom)

• Headset Spacers: 3 x 10mm

• Saddle: Norco XC | Steel Rails

• Grips: DDK Lock-On | 139mm Length

• Pedals: Nylon Flat Pedals

• Seatpost Clamp: Norco Alloy QR | 34.9mm Inner Diameter

Wheels & Tires

• Front Hub: Formula DC-1420 | 9x100mm QR | 32H | 6-Bolt

• Rear Hub: Formula DC-1422 | 10x135mm QR | HG | 32H | 6-Bolt

• Rims: DP 27 | 27mm Internal Width | 32H

• Front Tire: CY H-5162 | 60 TPI | Wire Bead

• Rear Tire: CY H-5162 | 60 TPI | Wire Bead

• Spokes/Nipples: Stainless Steel | 14g

Geometry
